VQ106P 6.5-inch active line array speaker

Description

Frequency Response: 80 Hz ~ 18 kHz (±3 dB) 60 Hz ~ 20 kHz (-10 dB)
Nominal Directivity (-6dB): 100° (H) 10° (V)
Sensitivity (@1W/1m): HF/LF: 108 dB SPL / 92 dB SPL
Speaker Power: HF/LF: 60W/200W (AES)
Impedance: HF/LF: 8/8 Ω
Maximum SPL: HF: 130 dB SPL peak
LF: 121 dB SPL peak
Speaker Drivers: 1 × 6.5" woofer (65mm voice coil)
1 × 1.34" compression tweeter (34mm voice coil)
Product Dimensions: H x W x D: 191 x 350 x 260mm
Weight: 9 kg

View Product Details

describe

This brand-new compact active line array system, paired with a precisely tuned DSP amplifier, offers a more portable and flexible professional sound reinforcement solution for small to medium-sized venues, featuring precise sound field control and a compact footprint. From material selection and structural design to product performance, this series incorporates cutting-edge concepts in the professional audio industry and integrates numerous innovative elements, marking another product line that advances toward miniaturization and intelligent functionality.

System Data
Frequency Response: 80 Hz – 18 kHz (±3 dB) 60 Hz – 20 kHz (-10 dB)
Nominal Coverage (-6 dB): 100° (H) 10° (V)
Sensitivity (@1W/1m): HF/LF: 108 dB SPL / 92 dB SPL
Speaker Power: HF/LF: 60 W / 200 W (AES)
Impedance: HF/LF: 8 / 8 ohms
Maximum Sound Pressure Level: HF: 130 dB SPL peak
LF: 121 dB SPL peak
Speaker Drivers: 1×6.5" woofer (65mm voice coil)
1×1.34" compression tweeter (34mm voice coil)
Physical Specifications
H x W x D: 191 x 350 x 260mm
Weight: 9 kg
Connectors: 2x4-pin Neutrik NL4 speaker sockets
Wiring: HF: 1+1- LF: 2+2-
Cabinet Material: 18mm birch plywood
Finish: Black Chameleon polyurea paint
Grille: Black steel mesh with oval perforations and acoustic, water-resistant speaker fabric
Angle: Adjustable to 0, 1.5, 3, 4.5, 6, 7.5°
