Available Bandwidth: 40 Hz - 20 kHz (-10 dB)
Speaker Power: HF 80W/LF 800W
Sensitivity Levels: LF: 97dB±2dB HF: 108dB±2dB
Maximum SPL: 143 dB
Horizontal Directivity: 110°
Driver Size: HF: 1 x 3-inch compression tweeter
LF: 2 x 12-inch woofers (75mm voice coil)
Driver Impedance: LF: 2 x 16 Ω, HF: 8 Ω
Cabinet Dimensions: 846 mm (W) x 363 mm (H) x 580 mm (D)
Cabinet Weight: 42 kg
Frequency Response: 28 Hz ~ 180 Hz (±3 dB) 26 Hz ~ 250 Hz (-10 dB)
Characteristic Sensitivity Level: 102 dB SPL
Maximum SPL: 138 dB±2 dB
Speaker Power: 1600 W
Peak Power: 3200 W
Impedance: 4Ω
Speaker Drivers: 2 x 18" (100mm voice coil) woofers
Cabinet Dimensions: 846 mm (W) x 575 mm (H) x 801 mm (D)
Weight: 90 kg
Speaker Type: Two-way vertical linear source array loudspeaker
Available Bandwidth: 45 Hz - 20 kHz (-10 dB)
Speaker Power: HF 80W/LF 600W
Speaker Peak Power: HF 160W/LF 1200W
Sensitivity Levels: LF: 99dB±2dB HF: 108dB±2dB
Maximum SPL: 143 dB
Horizontal Directivity: 110°
Driver Size: HF: 1 x 3-inch compression tweeter
LF: 2 x 10-inch woofers (75mm voice coil)
Driver Impedance: LF: 2 x 16 Ω, HF: 8 Ω
Cabinet Dimensions: 816 mm (W) x 319 mm (H) x 402 mm (D)
Cabinet Weight: 32 kg
Frequency Response: 40 Hz ~ 150 Hz (±3 dB) 30 Hz ~ 200 Hz (-10 dB)
Characteristic Sensitivity Level: 99 dB SPL
Maximum SPL: 133 dB±2 dB
Speaker Power: 800 W
Peak Power: 1600 W
Impedance: 8Ω
Speaker Driver: 1 x 18" (100mm voice coil) woofer
Cabinet Dimensions: 816 mm (W) x 575 mm (H) x 756 mm (D)
Weight: 55 kg
Speaker Type: Two-way vertical linear source array loudspeaker
Available Bandwidth: 50 Hz - 20 kHz (-10 dB)
Speaker Power: HF 80W/LF 500W
Speaker Peak Power: HF 160W/LF 1000W
Sensitivity Levels: LF: 99dB±2dB HF: 106dB±2dB
Maximum SPL: 141 dB
Driver Size: HF: 1 x 3-inch compression tweeter
LF: 2 x 8-inch woofers (65mm voice coil)
Driver Impedance: LF: 2 x 16 Ω, HF: 8 Ω
Cabinet Dimensions: W 686 x H 279 x D 552 mm
Cabinet Weight: 28 Kg
Frequency Response: 40 Hz ~ 200 Hz (±3 dB) 30 Hz ~ 320 Hz (-10 dB)
Sensitivity Level: 100 dB SPL
Maximum SPL: 136 dB±2 dB
Speaker Power: 1000 W
Peak Power: 2000 W
Impedance: 4Ω
Speaker Drivers: 2 x 15" (75mm voice coil) woofers
Cabinet Dimensions: 686 mm (W) x 480 mm (H) x 630 mm (D)
Weight: 60 kg
Patented technology; Midrange and bass phase plug loading technology
Available bandwidth: 50 Hz ~ 18 kHz (±3 dB)
40 Hz ~ 20 kHz (-10 dB)
Speaker power: HF100W/MF500W/LF800W
Speaker peak power: HF200W/MF1000W/LF1600W
Characteristic sensitivity levels: HF 113 dB SPL / MF 105 dB SPL / LF100 dB SPL
Maximum SPL levels: HF: 135/141 dB SPL peak
MF: 130/136 dB SPL peak
LF: 129/135 dB SPL peak
Vertical directivity: 90° (vertical) vertically adjustable
Speaker angle adjustment: 0.25, 1, 2, 3, 4, 5, 7.5 or 10°
Horizontal directivity: 110°
Driver size: HF 1 x 3" Neodymium magnet compression tweeter
MF 2 x 8" (60mm voice coil) neodymium magnet midrange
LF 2 x 12" (75mm voice coil) neodymium magnet woofer
Driver impedance: LF: 2 x 16Ω, MF: 2 x 16Ω, HF: 8Ω
Cabinet dimensions: W 1250 x H 366 x D 604 mm
Cabinet weight: 65 Kg
Patented Technology; Midrange and Bass Phase Plug Loading Technology
Available Bandwidth: 60 Hz ~ 18 kHz (±3 dB)
75 Hz ~ 20 kHz (-10 dB)
Speaker Power: HF100W/MF360W/LF700W
Speaker Peak Power: HF200W/MF720W/LF1400W
Characteristic Sensitivity Levels: HF 113 dB SPL / MF 105 dB SPL / LF100 dB SPL
Maximum SPL Levels: HF: 132/138 dB SPL peak
MF: 126/132 dB SPL peak
LF: 122/131 dB SPL peak
Vertical Directivity: 90° (Vertical) Vertically Adjustable
Driver Size: HF 2 x 1.75" Neodymium Magnet Compression Tweeter
MF 4 x 5" (41mm Voice Coil) Neodymium Magnet Midrange
LF 2 x 10" (75mm voice coil) Neodymium magnet woofer
Driver impedance: LF: 2 x 16Ω, MF: 2 x 16Ω, HF: 8Ω
Cabinet dimensions: W 996 x H 317 x D 454 mm
Cabinet weight: 58 Kg
Patented Technology; Midrange and Bass Phase Plug Loading Technology
Available Bandwidth: 60 Hz ~ 18 kHz (±3 dB)
70 Hz ~ 20 kHz (-10 dB)
Speaker Power: HF100W/MF320W/LF500W
Speaker Peak Power: HF200W/MF640W/LF1000W
Characteristic Sensitivity Levels: HF 103 dB SPL / MF 102 dB SPL / LF 98 dB SPL
Maximum SPL Levels: HF: 132/138 dB SPL peak
MF: 112/126 dB SPL peak
LF: 125/130 dB SPL peak
Driver Size: HF 2 x 1.75" Neodymium Magnet Compression Tweeter
MF 4 x 4.5" (30mm Voice Coil) Neodymium Magnet Midrange
LF 2 x 8" (65mm voice coil) Neodymium magnet woofer
Enclosure dimensions: 852mm (W) x 295mm (H) x 420mm (D)
Enclosure weight: 49kg
Nominal Power (AES): 800W
Peak Power: 1600W
Nominal Impedance: 8Ω
Operating Frequency Response: 32 Hz ~ 180 Hz (±3 dB), 30 Hz ~ 250 Hz (-10 dB)
Sensitivity (@1W/1m): 100dB
Maximum SPL Peak: 129 dB / 135 dB
Driver: 1×18" Waterproof Coated Driver
Net Weight/Gross Weight: 42kg
Product Dimensions (W×D×H): 523×703×694mm
Frequency Response: 80 Hz ~ 18 kHz (±3 dB) 60 Hz ~ 20 kHz (-10 dB)
Nominal Directivity (-6dB): 100° (H) 10° (V)
Sensitivity (@1W/1m): HF/LF: 112 dB SPL / 96 dB SPL
Speaker Power: HF/LF: 80W/350W (AES)
Impedance: HF/LF: 8/8 ohm
Maximum SPL: HF: 137 dB SPL peak
LF: 127 dB SPL peak
Speaker Drivers: 1×10" woofer (75mm voice coil)
1×1.75" compression tweeter (44mm voice coil)
Product Dimensions: H x W x D: 275 x 520 x 380mm
Weight: 13 kg
Frequency Response: 80 Hz ~ 18 kHz (±3 dB) 60 Hz ~ 20 kHz (-10 dB)
Nominal Directivity (-6dB): 100° (H) 10° (V)
Sensitivity (@1W/1m): HF/LF: 111 dB SPL / 95 dB SPL
Speaker Power: HF/LF: 60W/280W (AES)
Impedance: HF/LF: 8/8 ohm
Maximum SPL: HF: 134 dB SPL peak
LF: 122 dB SPL peak
Speaker Drivers: 1×8" woofer (65mm voice coil)
1×34" compression tweeter (34mm voice coil)
Product Dimensions: H x W x D: 231 x 430 x 325 mm
Weight: 11 kg
Frequency Response: 80 Hz ~ 18 kHz (±3 dB) 60 Hz ~ 20 kHz (-10 dB)
Nominal Directivity (-6dB): 100° (H) 10° (V)
Sensitivity (@1W/1m): HF/LF: 108 dB SPL / 92 dB SPL
Speaker Power: HF/LF: 60W/200W (AES)
Impedance: HF/LF: 8/8 Ω
Maximum SPL: HF: 130 dB SPL peak
LF: 121 dB SPL peak
Speaker Drivers: 1 × 6.5" woofer (65mm voice coil)
1 × 1.34" compression tweeter (34mm voice coil)
Product Dimensions: H x W x D: 191 x 350 x 260mm
Weight: 9 kg
Amplifier Power: 600W + 600W + 1200W (Class D digital amplifier with DSP digital processor) Rated Power: 800W
Peak Power: 1500W
Rated Impedance: 8 Ω
Frequency Range: 20Hz-150Hz
Sensitivity: 102dB System Components: LF unit 18-in ×1
Dimensions (H x W x D): 650 x 520 x 520mm
Input Connections: 4 x Euroblock
Net Weight: 40 KG
Amplifier Power: 300W + 300W + 800W (Class D digital amplifier with DSP digital processor) Rated Power: 500W
Peak Power: 900W
Rated Impedance: 8 Ω
Frequency Range: 20Hz-150Hz
Sensitivity: 101dB
System Components: LF unit 12-in ×1
Dimensions (H x W x D): 570 x 350 x 350mm
Input Connections: 4 x Euroblock
Net Weight: 26 KG
Amplifier Power: 300W + 300W + 800W (Class D digital amplifier with DSP digital processor) Rated Power: 500W
Peak Power: 900W
Rated Impedance: 8 Ω
Frequency Range: 20Hz-150Hz
Sensitivity: 101dB
System Components: LF unit 12-in ×1
Dimensions (H x W x D): 570 x 350 x 350mm
Input Connections: 4 x Euroblock
Net Weight: 26 KG
