VQ10AW Dual 10-Inch All-Weather Waterproof Line Array Speakers

2-way vertical linear source array loudspeakers

Description

Patented Technology: Bass Phase Plug Loading Technology
Available Bandwidth: 45 Hz - 20 kHz (-10 dB)Speaker Power: HF 80W/LF 600W
Speaker Peak Power: HF 160W/LF 1200W
Sensitivity Levels: LF: 99dB±2dB HF: 108dB±2dB
Maximum SPL: 143 dB
Driver Size: HF: 1 x 3-inch neodymium magnet compression tweeter
LF: 2 x 10-inch woofers (75mm voice coil)
Driver Impedance: LF: 2 x 16 Ω, HF: 8 Ω
Cabinet Dimensions: W 730 x H 325 x D 541 mm
Cabinet Weight: 36 Kg

View Product Details

describe

The Valtec Tubesound VQ® series is designed for extreme outdoor environments and is tailored for outdoor cultural and tourism projects as well as large-scale public address systems.

1. By combining a reinforced fiberglass (FRP) coated enclosure with composite waterproof coating technology, it delivers a professional audio solution that offers a three-in-one protection against water, impact, and corrosion.

2. Whether facing torrential rain, sandstorms, or salt fog corrosion, it consistently delivers pristine sound, redefining the standards for durability and audio quality in outdoor sound systems.

3. Industrial-grade materials, featuring epoxy resin and high-density fiberglass laminate construction, deliver a 300% increase in impact resistance.

4. Sealed construction with reinforced waterproof coatings at vulnerable seams and an internally reinforced frame design achieves IP66-rated water and dust resistance.

5. Corrosion-resistant and certified to pass the ISO standard 2000-hour salt spray test, it withstands acid rain, seawater, and corrosive gases from chemical plants.

6. Water- and dust-resistant, with a wide operating temperature range from -20°C to +100°C (passed 72-hour high-low temperature cycling tests).

7. Wind and sand resistance, compliant with MIL-STD-810G dust protection standards, suitable for desert and mining environments.

8. Designed for outdoor cultural tourism projects, high-end entertainment venues, and large-scale public address systems.

System Data
Speaker Type: Two-way vertical line array speaker
Patented Technology: Bass phase plug loading technology
Frequency Response: 45 Hz – 20 kHz (-10 dB)
Speaker Power: HF 80 W / LF 600 W
Peak Power: HF 160 W / LF 1200 W
Sensitivity Levels: LF: 99 dB ± 2 dB; HF: 108 dB ± 2 dB
Maximum Sound Pressure Level: 143 dB
Vertical Coverage: Depends on the number of speakers and line array curvature
Vertical Angle Adjustment: 0.25, 1, 2, 3, 4, 5, 7.5, or 10°
Horizontal Coverage: 110°
Driver Dimensions: HF: 1 x 3-inch neodymium compression tweeter
LF: 2 x 10-inch woofers (75mm voice coil)
Driver Impedance: LF: 2 x 16 Ω, HF: 8 Ω
Input Connection: 4-pin PA-COM®
LINK Connection: 4-pin PA-COM®
Connector: LP28 waterproof aviation connector (4-pin)
Wiring Configuration: 1-2+…HF, 3-4+…LF
Material: 18mm birch plywood
Finish: Black polyurea paint
Grille: Front grille lined with acoustic mesh
Cabinet Dimensions: W 730 x H 325 x D 541 mm
Cabinet Weight: 36 kg
